Board Edger Systems

Our unique patented approach permits you to process up to 60 boards per minute* while keeping the lowest possible feed speed at the board edger.

The patented servo positioning modules** position boards swiftly, smoothly and accurately, one after the other, within as low as 0.6 second gap.


Another key element of our high speed system is the commonly underestimated challenge of bringing boards consistently to the edger's infeed. To overcome this challenge, we have developed our lugless staging transfer system.



Highlights of the different characteristics and options available.

  • Reverse angle camel back unscrambler with integrated even end line

  • Lugless staging transfers

  • Comact optimization and controls

  • Servo controlled positioning belts

  • Full control of the boards from waiting position to sawing position

  • Servo positioned press rolls

  • ADM monocoque design integrates infeed and saw box for maximum accuracy and simplicity

  • Fewer moving parts

  • Reduced maintenance



Highlights of the different characteristics and options available:

  • Cueing and scanning transfer using pin stops

  • Servo controlled positioning belts

  • Full control of the boards from waiting position to sawing position

  • Fewer moving parts

  • Reduced maintenance

* Piece-count calculated for 8’ flitches.
** Canadian patent: CA 2,926,562 / US patent: US 9,415,950 B1

Medium Speed Systems

Using a similar design concept as the high speed systems, we have developed a medium speed system to accommodate those mills with piece-counts of approximately 30 pieces per minute*. This system is designed to be well suited for many hardwood sawmills.
